SPECIFICATION:

• Voltage : 24 v – 36 v- 48 v
• Power : 250 w – 350 w – 450 w
• Motor type : Brush less gear less hub motor
• Gross weight : 3.2 kg
• The tire diameter : 83 mm
• Tire width : 40 mm
• The motor cable length : 20 to 50 cm
• Hall sensor quantity : 3
• No-load speed: 24 v 250 rpm (0.35 A) 36 v 450 rpm (0.38 A) 48 v 650 rpm (0.42 A) 60 v 800 rpm (0.61 A)
• Rated speed : 250 – 800 rpm
• Rated torque: 8-15 NM
• Brakes : Disc Break
• Load carrying capacity : 40 Kg – 120 Kg
• Rated Efficiency : > 85%
• Noise : Maximum speed can be achieved : 30 – 40 Km / Hr
• Constant current at Ideal Load : 5-15 Ampere
